GN24-12D indoor High voltage disconnecting switch

WeChat: 0086-18668775151

Skype me: copecoelectric

Print this page Request for Quote

Lead time: Sample is available in 2-3 working days;
The regular order will be usually 20-30 working days after receipt of 30% advance payment

Quality Guarantee: We offer 18 months’ warranty period, and 20 years’ quality guarantee period

Payment Terms: T/T, L/C, Western Union or Paypal

Trade term: FOB or CIF prices

We’re professional OEM manufacturer, and also accept the customized products according to the supplied drawings or parameters

Description
GN24-12D indoor High voltage disconnecting switch applies to power system of rated voltage below 12KV, AC 50/60Hz. It is equipped with CS6-1 manual-operating mechanism and is used to break and make circuit under no-load. There are additional pollution type, high-altitude type and electrified display..

Environment condition
- Ambient temperature: max. 40°C min. -30°C
- Altitude: ≤3000m
- Wind pressure: ≤700Pa (equals to wind speed 34m/s)
- Relative humidity: daily average ≤95%, monthly average ≤90%
- Earthquake intensity: ≤8 degree
- No corrosive, explosive or flammable gas, no violent vibration

Technical Data

Model	Rated voltage (kV)	Rated current (A)	4s rated short time withstand current (kA)	Rated peak withstand current (kA)
GN24-12D/630-20	12	630	20	50
GN24-12CD/630-20	12	630	20	50
GN24-12SD/630-20	12	630	20	50
GN24-12CSD/630-20	12	630	20	50
GN24-12D/1000-31.5	12	1000	31.5	80
GN24-12CD/1000-31.5	12	1000	31.5	80
GN24-12SD/1000-31.5	12	1000	31.5	80
GN24-12D/1250-40	12	1250	40	100
GN24-12SD/1250-40	12	1250	40	100
GN24-12CD/1250-40	12	1250	40	100
